Semi-automatic Capping Machine
A semi-automatic capping machine is designed to assist in the bottle capping process but requires some manual intervention. It is a smart investment for small to medium-scale businesses to improve efficiency and productivity in their packaging operations.
- Cap headings can be customized according to the size of the bottle;
- Space-saving structure, ideal for businesses with limited areas;
- Reduces manual labor while increasing the capping speed and uniform capping quality.
Semi-auto Capping Machine
Semi-automatic capping machine is a specialized piece of equipment designed to assist in the bottle capping process but requires some manual intervention. For instance, the operator needs to manually place the cap onto the container and position the container under the capping head. Once in place, the machine employs mechanical or pneumatic systems to securely tighten the cap, ensuring a consistent and reliable seal. Furui Machinery offers two types of semi-automatic bottle capping machines, featuring either chucks or spindles, to cater to various production needs. These machines are available in a compact benchtop design or a floor-standing model, providing flexibility to suit different workspace setups. Below are additional parameters for your reference.
Semi-auto Spindle Capping Machine
Chuck Capping Machine
| Model | SGJ-6100 (Spindle Capper) | DDX-450 (Chuck Capper) |
| Voltage | 220V 50/60Hz | 220V 50/60Hz |
| Cap Diameter | 20-50mm | 10-50mm |
| Bottle Height | 50-400mm | 40-200mm |
| Capping Speed | 30-45 bottles/min | 20-40 bottles/min |
| Package Size | 480*400*580 mm | 520*300*530mm |
| Weight | 30kg | 32kg |
| Suitable Bottles | Glass/plastic bottles/tin cans/jars, flat/square/hexagonal/round/special-shaped bottles, etc. | |
| Caps | Screw caps, spray caps, pump caps, etc. | Round screw caps, tinplate caps, etc. |
Differences Between Semi-auto and Auto Capping Machines
Semi-auto Capping Machine
- Requires some manual intervention. The operator needs to place the cap on the bottle and position the bottle under the capping head. Once in position, the machine automatically tightens the cap.
- Slower compared to fully automatic systems. Suitable for low to medium production volumes.
- More affordable and more compact.
Automatic Capping Machine
- The fully automatic system uses a conveyor belt to feed bottles, a cap feeder to place caps, and then automatically tightens and seals the bottles, all without the need for operator assistance.
- Much faster and can handle higher production volumes, making it ideal for large-scale production.
- More expensive and requires more space for the system.
Features of Semi-automatic Capping Machine
High Tightening Quality
Our machine ensures a high rate of qualified cap tightening, providing consistent and secure seals for every bottle, reducing the risk of leakage or improper capping.
Easy Adjustment
It is easy to adjust settings to suit different bottle heights. This makes the machine highly versatile and suitable for different production needs without a complex setup.
Reliable Performance
Equipped with world-renowned pneumatic components and branded parts, our machine boasts a low failure rate and ensures stable, reliable performance throughout its lifecycle.
Conclusion
In conclusion, a semi-automatic capping machine is a reliable, cost-effective solution for improving your bottle capping process, especially for small to medium-scale production needs. With Furui Machinery's versatile options, including chuck and spindle models in both benchtop and floor-standing designs, you can find the perfect machine to enhance efficiency and ensure consistent, high-quality results. In addition to capping machines, we provide a range of packaging solutions, including labeling machines, heat shrink wrapping machines, and more. Contact us today for more details!
